Berikan sentuhan dan pengalaman visual Anda yang luar biasa !!!
 |
| Tempat asal: | Guangdong, Cina |
| Nama merek: | ZXTLCD |
| Sertifikasi: | CE/Rohs/FCC |
| Nomor model: | ZXTLCD-E185WAB |
| Kuantitas min Order: | 1 |
|---|---|
| Harga: | negotiable |
| Kemasan rincian: | kotak kayu, karton, kotak penerbangan adalah opsional |
| Waktu pengiriman: | 3-5 hari kerja |
| Syarat-syarat pembayaran: | L/C, T/T, Western Union, MoneyGram |
| Menyediakan kemampuan: | 2000pcs per bulan |
| Screen Size: | 18.5 inch | Aspect Ratio: | 16:9 |
|---|---|---|---|
| Brightness: | 400 cd/m² | Install Type: | Embedded, open-frame, wall-mounted, floor-standing |
| Suitable Environment: | Outdoor; Indoor | Applications: | Industrial control, medical equipment, automotive systems, various self-service terminals (new retail vending machines/financial terminals/information kiosks/parcel lockers/storage lockers/garbage recycling cabinets/charging stations, etc.), hospitality an |
| Parameter panel LCD | Ukuran layar | 18.5 inci | ||
| Area Tampilan | 409.8 mm. (Tinggi) X 230.4 (Lebar) mm. | |||
| Rasio aspek | 16: 9 | |||
| Jenis LCD | a-Si TFT-LCD Monitor | |||
| Resolusi Maksimal | 1920 X 1080 | |||
| Tampilkan Warna | 16.7m, 72% NTSC | |||
| Cahaya | 250cd/m2 | |||
| Rasio Kontras | 1200: 1 | |||
| Sudut pandang (ke atas/ke bawah/kiri/kanan) | 89°/89°/89°/89° (jenis) | |||
| Waktu Tanggapan | 14ms | |||
| Umur panel LCD (jam) | 60,000 ((Jam.) | |||
| Frekuensi medan | 60Hz | |||
| Parameter audio | Sistem audio | Stereo | ||
| Ukuran speaker | ≈ 99 x 45 x 20 mm | |||
| Impedansi | 8 Ohm | |||
| Kekuatan | 2 x 5 watt | |||
| Suara keras | > 80 decibel | |||
| Antarmuka | Konektor 4 pin | |||
| Konfigurasi PCB Android bawaan (Pilih salah satu dari dua) | CPU | Quad-Core RK3288, 1,8GHz | Quad-Core RK3568,2.0GHz | |
| GPU | Mali-T764 | Mali-G52 | ||
| RAM | 2GB | 4GB | ||
| ROM | 32GB | 32GB | ||
| Sistem Android | Android 10.0 | Android 11 | ||
| Ethernet | 1 x RJ45, 1.000 Mbps | Ethernet 1.000 Mbps | ||
| Internet nirkabel | 2.4Ghz | 2.4 Gigahertz/5 Gigahertz, Wi-Fi 6 | ||
| Bluetooth | 4.2 | 5 | ||
| Antarmuka | USB2.0 x 2 | OTG USB2.0 x 1 | ||
| Kekuatan | Sumber Daya | Arus bolak-balik 100V ~ 240V, 50/60Hz | ||
| Kerugian Daya Maksimal | ≤ 30 Watt | |||
| Kegagalan daya dalam modus tunggu | < 1 watt | |||
| Fitur | Suhu operasi | 0°C ~ 50°C | ||
| Suhu penyimpanan | Di bawah 10°C ~ +60°C | |||
| Ukuran Paket | Dimensi Perangkat | 470.9 x 294.9 x 50mm | ||
| Berat bersih | 60,5 kilogram | |||
| Ukuran Paket | 55 x 38 x 15 sentimeter | |||
| Berat Paket Bruto Per Satuan | 7 kilogram | |||
